RIGOL MSO5354数字示波器显波器

Rigol MSO5354 Digital Oscilloscope

The MSO5354 is a 350MHz, 4CH high-performance Digital Oscilloscope model design based on RIGOL UltraVision II technology. The MSO5000 series integrates 7 independent instruments into one. The MSO5000 series offers a high sample rate / bandwidth ratio, high memory depth, clear 9 inch touch-screen display, excellent waveform capture rate and powerful data analysis functions. Many of its specifications are industry leading. These instruments are expected to be popular for R&D, univerSITIes, production , quality control, communications engineering, automotive engineering, aerospace engineering, industrial and power markets.

Features:

• Analogue bandwidth: 350 MHz; bandwidth upgrade option supported

• 2 or 4 analogue channels (upgradeable), standard 16 digital channels(LA probe required)

• Up to 8 GSa/s real-time sample rate

• Up to 200 Mpts memory depth (option)

• High waveform capture rate (over 500,000 wfms/s)

• Auto measurement of 41 waveform parameters; full-memory hardware measurement function

• A variety of serial protocol triggers and decodes

• NEW Bode Plot Analysis – Automate advanced device characterisation with new phase and gain analysis capabilities

• Up to 450,000 frames of hardware real-time and ceaseless waveforms recording and playback functions

• Independent search, navigation keys, and event table

• Built-in advanced power analysis software (option)

• Integrates 7 independent instruments into 1, including a digital oscilloscope, a logic analyser, a spectrum analyser, an arbitrary waveform generator, a digital voltmeter, a frequency counter and totaliser, and a protocol analyser

• 9-inch capacitive multi-touch screen, 256-level intensity grading display, with colour persistence

• Multiple interfaces available: USB HOST&DEVICE, LAN(LXI), HDMI, TRIG OUT, and USB-GPIB

• Web Control remote command

• Unique online version upgrade

• Novel and delicate industrial design, easy to operate

• Supplied with… 4-off passive probes (500MHz), USB cable, UK & European mains leads, quick guide

Rigol MSO5000 Oscilloscope Comparison Table
